Series 600 Mini hinges - 94° opening - Positive angled application - SALICE-1

SELF-CLOSING

Series 600 Mini hinges - 94° opening - Positive angled application

Sprung hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional mounting plates
Compact, elegant, very strong mini hinge.
  • For wooden doors with positive angled assembly.
  • 11,5 mm deep metal cup.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 8 mm.
  • Compatible with all traditional Series 200 mounting plates.
  • NOT COMPATIBLE with Domi snap-on mounting plates.
C6_7U99
Arm 24°
C6_7E99
Arm 30°
C6_7M99
Arm 45°
Screw cover cap S6XX83C1

Plastic screw cover cap with symmetrical printed logo. For all Series 600 hinges

S6SX83C1 - S6DX83C1
Plastic screw cover cap with asymmetrical printed logo. For all Series 600 hinges

Spacer S6A786XG
Spacer for hinges with 26 mm diameter.
To be used to reduce the cup drilling depth by 1.5 mm
