Series 900 - 110° opening - Standard application - SALICE-1

SELF-CLOSING

Series 900 - 110° opening - Standard application

Sprung hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 110° opening
  • Screw fixing with traditional mounting plates
Hinges developed to solve all applications
  • For doors with a minimum thickness of 13mm, or with moulded profiles.
  • Dimensions of the Ø 35 mm cup.
  • 11 mm deep metal cup.
  • 110° opening.
  • Possible drilling distance on the door (K): from 3 to 6 mm.
  • Compatible with all traditional Series 200 mounting plates.
  • NOT COMPATIBLE with Domi snap-on mounting plates.
C9_6C99
Arm 0
C9_6J99
Arm 5
C9_6L99
Arm 9
C9_BS99
Arm 17
Screw cover cap S9XX83H9
Symmetrical steel screw cover cap, it can be personalised on request.
For Series 900 hinges
Screw cover cap S9CX83H9
Symmetrical steel screw cover cap with embossed logo.
For Series 900 hinges
Screw cover cap S9XX83C1
Symmetrical plastic screw cover cap, it can be personalised on request.
For Series 900 hinges
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Flange cover cap S2CX85H9
Steel flange cover cap with embossed logo.
For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
