SELF-CLOSING

Series 200 - 94° opening - Application for fridge doors

Sprung hinge

  • For thicker doors (19-35 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional mounting plates
The Series 200 make up an integrated system of hinges developed to provide a solution to any situation involving concealed hinges.
  • Hinges for fridge doors.
  • Dimensions of the Ø 35 mm cup.
  • 11 mm deep metal cup.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 9 mm.
  • Compatible with all traditional Series 200 mounting plates.
  • NOT COMPATIBLE with Domi snap-on mounting plates.
C2_BF99
Hinges for fridge doors
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.
For Series 100, 200, 700, F, M, 400 and universal hinges
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
Screw cover cap S2XX83A1
Symmetrical plastic screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, B, M and 400 hinges
