SELF-CLOSING Series 600 Mini hinges - 94° opening - Standard application-1

SELF-CLOSING

Series 600 Mini hinges - 94° opening - Standard application

Sprung hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional mounting plates
Compact, elegant, very strong mini hinge.
  • 11.5 mm deep metal cup.
  • 26 mm cup diameter.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 8 mm.
  • Compatible with all traditional Series 200 mounting plates.
  • NOT COMPATIBLE with Domi snap-on mounting plates.
C6_7C99
Arm 0
C6_7L99
Arm 9
C6_7S99
Arm 17
Screw cover cap S6XX83C1

Plastic screw cover cap with symmetrical printed logo. For all Series 600 hinges

S6SX83C1 - S6DX83C1
Plastic screw cover cap with asymmetrical printed logo. For all Series 600 hinges

Spacer S6A786XG
Spacer for hinges with 26 mm diameter.
To be used to reduce the cup drilling depth by 1.5 mm
