SELF-CLOSING

Series 400 Mini hinges - 94° opening - Positive angled application and crampon hinges

Sprung hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 94° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
Compact, elegant, very strong mini hinge.
  • Hinges for doors with positive angled assembly and crampon hinges.
  • 11.5 mm deep metal cup.
  • 26 mm cup diameter.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 8 mm.
C4_7E99
Arm 30°
Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates
C4_7M99
Arm 45°
Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates
C4_7N99
Crampon hinge.
To be used only with Series 200 mounting plates for traditional assembly and drilling 28x32mm
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.
For Series 100, 200, 700, F, M, 400 and universal hinges
Screw cover cap S2XX83A1
Symmetrical plastic screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, 400 and universal hinges
Spacer S6A786XG
Spacer for hinges with 26 mm diameter.
To be used to reduce the cup drilling depth by 1.5 mm
