SELF-CLOSING

Series 600 Mini hinges - 94° opening - Crampon hinge for smaller spaces

Sprung hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional mounting plates
Compact, elegant, very strong mini hinge.
  • Crampon hinges.
  • For smaller spaces with 15x32 mm drilling.
  • 11.5 mm deep metal cup.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 8 mm.
  • Compatible with all traditional Series 200 mounting plates, 28x32 mm drilling.
  • NOT COMPATIBLE with Domi snap-on mounting plates.
C6_7N99
Crampon hinge
Screw cover cap S6XX83C1

Plastic screw cover cap with symmetrical printed logo. For all Series 600 hinges

S6SX83C1 - S6DX83C1
Plastic screw cover cap with asymmetrical printed logo. For all Series 600 hinges

Spacer S6A786XG
Spacer for hinges with 26 mm diameter.
To be used to reduce the cup drilling depth by 1.5 mm
