Hinges developed to solve all applications
- When a greater opening angle is required.
- Dimensions of the Ø 35 mm cup.
- 11 mm deep metal cup.
- 110° opening.
- Possible drilling distance on the door (K): from 3 to 6 mm.
- Compatible with all traditional steel Series 200 mounting plates.
C8_6C99
Arm 0
C8_6J99
Arm 5
C8_6L99
Arm 9
C8_BS99
Arm 17
Screw cover cap S8XX83H9
Symmetrical steel screw cover cap, it can be personalised on request.For Series 800 hinges
Screw cover cap S8CX83H9
Symmetrical steel screw cover cap with embossed logo.For Series 800 hinges
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.For all Series 100, 200, 300, 700, 800 and 900
Flange cover cap S2CX85H9
Steel flange cover cap with embossed logo.For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
