SELF-CLOSING

Series 300 - 94° opening - Hinges with a small operating profile

Sprung hinge

  • For thicker doors (19-35 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional Series 300 mounting plates
Hinges with just 45 mm operating profile
  • Dimensions of the Ø 35 mm cup.
  • 11 mm deep metal cup.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 9 mm.
  • Compatible with all traditional Series 300 mounting plates.
C3_BA99
Arm 0
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Flange cover cap S2CX85H9
Steel flange cover cap with embossed logo.
For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
