SELF-CLOSING Series 200 - 155° opening - Standard application-1

SELF-CLOSING

Series 200 - 155° opening - Standard application

Sprung hinge

  • For doors of medium weight and thickness (16-26 mm)
  • Wooden doors
  • 155° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
The Series 200 make up an integrated system of hinges developed to provide a solution to any situation involving concealed hinges.
  • For min.10 mm thick doors.
  • Dimensions of the Ø 35 mm cup.
  • 8,5 mm deep die-cast cup.
  • 155° opening.
  • Possible drilling distance on the door (K) : from 3 to 9 mm.
  • Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
C2_KA99
Arm 0
C2_KD99
Arm 5
C2_KG99
Arm 9
C2_KP99
Arm 17
Flange cover cap S2KX85A_

Plastic flange cover cap

Available colours:
S2KX85A6 = Titanium
S2KX85A9 = Nichel-plated

Stop device S2AF37X3
It limits opening at about 135°
Stop device S2BF37XY
It limits opening at about 130°
Stop device S2AM37XG
It limits opening at about 120°
Stop device S2BM37XG
It limits opening at about 92°
