SELF-CLOSING Series 200 - 155° opening - Standard application-1

SELF-CLOSING

Series 200 - 155° opening - Standard application

Sprung hinge

  • For thicker doors (19-36 mm)
  • Wooden doors
  • 155° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
The Series 200 make up an integrated system of hinges developed to provide a solution to any situation involving concealed hinges.
  • For thicker doors max. 36 mm.
  • Hinge with greater opening angle and reduced operating profile.
  • Dimensions of the Ø 35 mm cup.
  • 11 mm deep die-cast cup.
  • 155° opening.
  • Possible drilling distance on the door (K): from 3 to 9 mm.
  • Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
C2_HA99
Arm 0
Flange cover cap S2KX85A_

Plastic flange cover cap

Available colours:
S2KX85A6 = Titanium
S2KX85A9 = Nichel-plated

Stop device S2BH37XG
It limits opening at about 110°
