SELF-CLOSING Series 100 - 105° opening - Standard application-1

SELF-CLOSING

Series 100 - 105° opening - Standard application

Sprung hinge

  • For doors of small weight and thickness (15-20 mm)
  • Wooden doors
  • 105° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
Hinges developed to solve all applications
  • For min. 10 mm thick doors.
  • Dimensions of the Ø 35 mm cup.
  • 8 mm deep metal cup.
  • 105° opening.
  • Possible drilling distance on the door (K): from 3 to 6 mm.
  • Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
C1_6A99
Arm 0
C1_6D99
Arm 5
C1_6G99
Arm 9
C1_6P99
Arm 17
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, N, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.
For Series 100, 200, 700, F, M, N, 400 and universal hinges
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
Screw cover cap S2XX83A1
Symmetrical plastic screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, 400 and universal hinges
