SELF-CLOSING Series 200 - 110° opening - Long crampon hinge-1

SELF-CLOSING

Series 200 - 110° opening - Long crampon hinge

Sprung hinge

  • For doors of medium weight and thickness (16-26 mm)
  • Wooden doors
  • 110° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
The Series 200 make up an integrated system of hinges developed to provide a solution to any situation involving concealed hinges.
  • Long crampon hinges.
  • Dimensions of the Ø 35 mm cup.
  • 11 mm deep metal cup.
  • 110° opening.
  • Possible drilling distance on the door (K): from 3 to 6 mm.
  • Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
C2_6N99AM
Long crampon hinge
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, N, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.
For Series 100, 200, 700, F, M, N, 400 and universal hinges
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Flange cover cap S2CX85H9
Steel flange cover cap with embossed logo.
For all Series 100, 200, 300, 700, 800 and 900
Stop device S2A637XF
It limits opening at about 86°
