SELF-CLOSING
Series N - 94° opening - Standard application
Sprung hinge
- For profile and thicker doors (20-40 mm)
- Wooden doors
- 94° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
For profile and thicker doors (max. 40 mm).
Technical features
- 12 mm deep cup.
- 40 mm cup diameter.
- 94° opening.
- Possible drilling distance on the door (K): from 3 to 14 mm.
- Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
Catalogue
Technical pamphlet
CN_7A99
Arm 0
CN_7A99 = nickel-plated finish
CN_7A66 = titanium finish
CN_7G99
Arm 9
CN_7G99 = nickel-plated finish
CN_7G66 = titanium finish
CN_7P99
Arm 22
CN_7P99 = nickel-plated finish
CN_7P66 = titanium finish
Screw cover cap S2BX83H_
Symmetrical steel screw cover cap.
S2BX83H9__ = Nickel-plated, can be personalised on request (screen printed)
S2BX83H6 = Titanium
NOT personalised
Screw cover cap S2MX83H_
Symmetrical steel screw cover cap.
With personalised embossed logo on request.
S2MX83H9_ _ = Nickel-plated
S2MX83H6_ _ = Titanium
Flange cover cap SNXX85A_
Plastic flange cover cap.
NOT personalised.
SNXX85A9 = Nickel-plated
SNXX85A6 = Titanium
Documentation
Video
-
Automatic closing
-
Traditional assembly with Series 200 mounting plates
-
Assembly with Domi snap-on mounting plates
-
Traditional height adjustment
-
Height adjustment by cam
-
Depth adjustment with Domi snap-on mounting plates - Model BAV
-
Depth adjustment with Domi snap-on mounting plates - Models BAPXR BARXR
-
Traditional depth adjustment
-
Sideways adjustment
-
Fixing: wood screw
-
Fixing: knock-in dowel
