Smoothness and silent movement
Coil-spring movement with a wide range of adjustment. For use on wooden and alu-framed doors.
Neatly-designed covers in white or titanium colour. EvoLift is suitable for a vast range of furniture applications: kitchens and livingroom furniture.
- Coil-spring movement with a wide range of adjustment
- For use on wooden and alu-framed doors
- Push version
- Neatly-designed covers in white or titanium colour
FRMFXXPDSN9_
FRMFXXPDSN9D: Weak system strength, right cabinet side
FRMFXXPDSN9S: Strong system strength, left cabinet side
Cover SR_M78A_SNXXF
SRDM78AQSNXXF: Right cabinet side, white colour
SRDM78ALSNXXF: Right cabinet side, titanium colour
SRSM78AQSNXXF: Left cabinet side, white colour
SRSM78ALSNXXF: Left cabinet side, titanium colour
C2_PA99
Hinge for wooden doors or for alu-framed doors 45 mm
Arm 0
C2_4A99
Hinge for wooden doors or for alu-framed doors 45 mm
Arm 0
C2ZPA99
Hinge for alu-framed doors min. 17 mm max. 24 mm
Arm 0
BAPGM39/16
Mounting plate for hinges
DLZXBH9
Support for plate for alu-framed doors min. 17 mm max. 24 mm
DPASNG
Release device to be used to increase the magnetic holding strength. It must always be used together with the DPM. The suggested position of the DPM is the point of pressure on the door. The DPA can be positioned at any point along the opening edge of the door.ø 10 mm, 40 mm length.
Grey
DPASNB
Release device to be used to increase the magnetic holding strength. It must always be used together with the DPM. The suggested position of the DPM is the point of pressure on the door. The DPA can be positioned at any point along the opening edge of the door.ø 10 mm, 40 mm length.
Beige
DPMSNB
Release device. ø 10 mm, 40 mm length.Beige
DPMSNG
Release device. ø 10 mm, 40 mm length.Grey
DP39XXG
Adjustable magnetic retaining.ø16.6 mm
DP28SN9
Retaining catch to be inserted.ø 11.5 mm
DP38XX91
Retaining catch with adhesive.20x14 mm.
Technical information
Documentation
Technical pamphlet
