Smoothness and silent movement
Two strength types dependent on door dimensions and weight. Coil-spring movement with a wide range of adjustment. For use on wooden and alu-framed doors.
Neatly-designed covers in white or titanium colour. EvoLift is suitable for a vast range of furniture applications: kitchens and livingroom furniture.
- Two strength types dependent on door dimensions and weight
- Coil-spring movement with a wide range of adjustment
- For use on wooden and alu-framed doors
- Soft close
- Neatly-designed covers in white or titanium colour
FRMFXXX_SN9_
FRMFXXXDSN9D: Weak system strength, right cabinet side
FRMFXXXDSN9S: Weak system strength, left cabinet side
FRMFXXXFSN9D: Strong system strength, right cabinet side
FRMFXXXFSN9S: Strong system strength, left cabinet side
Cover SR_M78A_SNXXF
SRDM78AQSNXXF: Right cabinet side, white colour
SRDM78ALSNXXF: Right cabinet side, titanium colour
SRSM78AQSNXXF: Left cabinet side, white colour
SRSM78ALSNXXF: Left cabinet side, titanium colour
C2_6A99
Hinge for wooden doors or for alu-framed doors 45 mm
Arm 0
C2Z6A99
Hinge for alu-framed doors min. 17 mm max. 24 mm
Arm 0
BAPGM39/16
Mounting plate for hinges
DLZXBH9
Support for plate for alu-framed doors min. 17 mm max. 24 mm
