Smoothness and silent movement
Two strength types dependent on door dimensions and weight. Coil-spring movement with a wide range of adjustment. For use on wooden and alu-framed doors.
Neatly-designed covers in white or titanium colour. EvoLift is suitable for a vast range of furniture applications: kitchens and livingroom furniture.
- Two strength types dependent on door dimensions and weight
- Coil-spring movement with a wide range of adjustment
- For use on wooden and alu-framed doors
- Soft close
- Neatly-designed covers in white or titanium colour
FLMF__X_SN9__
FLMF60X_SN9__: Arm length 60 cm
FLMF66X_SN9__: Arm length 66 cm
FLMF72X_SN9__: Arm length 72 cm
FLMF78X_SN9__: Arm length 78 cm
FLMF91X_SN9__: Arm length 91 cm
FLMF__XDSN9__: Weak system strength
FLMF__XFSN9__: Strong system strength
FLMF__X_SN9D_: Right cabinet side
FLMF__X_SN9S_: Left cabinet side
FLMF__X_SN9_A: Wood screw fixing, 48x6 mm drilling
FLMF__X_SN9_B: Dowel fixing, 48x6 mm drilling
FLMF__X_SN9_P: Wood screw fixing, 45x9.5 mm drilling
FLMF__X_SN9_U: Wood screw fixing, 52x5.5 mm drilling
FLMF__X_SN9_R: Dowel fixing, 45x9.5 mm drilling
FLMF__X_SN9_W: Dowel fixing, 52x5.5 mm drilling
Cover SB_M78A_SNXXF
SBDM78AQSNXXF: Right cabinet side, white colour
SBDM78ALSNXXF: Right cabinet side, titanium colour
SBSM78AQSNXXF: Left cabinet side, white colour
SBSM78ALSNXXF: Left cabinet side, titanium colour
C2_6A99
Hinge for wooden doors or for alu-framed doors 45 mm
Arm 0
FLC_E9R
Central hinge
BAPGM39/16
Mounting plate for hinges
Technical pamphlet
