Smoothness and silent movement
Two strength types dependent on door dimensions and weight. Coil-spring movement with a wide range of adjustment. For use on wooden and alu-framed doors.
Neatly-designed covers in white or titanium colour. EvoLift is suitable for a vast range of furniture applications: kitchens and livingroom furniture.
- Two strength types dependent on door dimensions and weight
- Coil-spring movement with a wide range of adjustment
- For use on wooden and alu-framed doors
- Soft close
- Neatly-designed covers in white or titanium colour
FPMF_XX_SN9
FPMFCXXDSN9: Short arm length, weak system strength
FPMFLXXDSN9: Long arm length, weak system strength
FPMFCXXFSN9: Short arm length, strong system strength
FPMFLXXFSN9: Long arm length, strong system strength
Cover SPXM78A_SNXXF
SPXM78AQSNXXF: White colourSPXM78ALSNXXF: Titanium colour
DBZXBH9
Support for plate for alu-framed doors min. 17 mm max. 24 mm
Stabiliser bar FPMF59_ ____
FPMF59Q X439: White colour, bar length for cabinet width from 600 mm
FPMF59Q X739: White colour, bar length for cabinet width from 900 mm
FPMF59Q 1039: White colour, bar length for cabinet width from 1200 mm
FPMF59L X439: Titanium colour, bar length for cabinet width from 600 mm
FPMF59L X739: Titanium colour, bar length for cabinet width from 900 mm
FPMF59L 1039: Titanium colour, bar length for cabinet width from 1200 mm
Technical pamphlet
Feel the design according to your favourite product
Learn about the other products
Learn about the other products
EVOLIFT
Flap door, soft close
Compactness and high levels of performance
- Wooden doors
- Aluminium-frame doors
- Coil-spring movement
- With covers
- Door height from 300 to 600 mm
- Door weight from 1,5 to 18 kg
EVOLIFT
Folding door, soft close
Compactness and high levels of performance
- Wooden doors
- Aluminium-frame doors
- Coil-spring movement
- With covers
- Door height from 570 to 940 mm
- Door weight from 3 to 16 kg
EVOLIFT
Swing opening door, soft close
Compactness and high levels of performance
- Wooden doors
- Aluminium-frame doors
- Coil-spring movement
- With covers
- Door height from 360 to 600 mm
- Door weight from 2,5 to 22 kg
EVOLIFT
Flap door, Push opening
Compactness and high levels of performance
- Wooden doors
- Aluminium-frame doors
- Coil-spring movement
- With covers
- Door height from 300 to 400 mm
- Door weight from 2 to 15 kg
WIND
With soft closing system for single doors
Small and compact lifting system fixed to the cabinet sides
- Wooden doors
- Door height from 220 to 600 mm
- Door weight from 1,5 to 24 kg
- 85° - 94° opening
- Adjustable spring strength
WIND
With Push system for single doors
Small and compact lifting system fixed to the cabinet sides
- Wooden doors
- Door height from 220 to 600 mm
- Door weight from 1,5 to 24 kg
- 85° - 94° opening
- Adjustable spring strength
VERTICAL SLIDING SYSTEM
Mover
Vertical sliding system for wall cabinet doors. The action of the system is synchronised and controlled, enabling the door to be held in any position
- Max. door weight from 6 to 23 kg
- Width from 900 to 2400 mm
- Height from 480 to 600 mm
- Thickness of the side from 18 to 20 mm
- The door can be held in any position
