UNIVERSAL HINGES PUSH
Universal hinges - 110° opening - Standard applicationHinges equipped with a special spring for the opening of handle-less doors
- Glass doors
- Integrated Push system
- No drilling is required
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
Universal (CBG) hinges have been developed for use on glass doors and mirrors.
They are fully adjustable in three directions and are compatible with all Salice mounting plates.
The Push-System is a self-opening system for the doors of all types of handleless furniture. It consists of a series of self-opening hinges, release devices that can be fitted to the top, base or side panel of the cabinet, and retaining catches to be fitted to the back of the door.
The universal hinge has been developed to provide a solution to most applications in the field of furniture doors.
Push hinges are equipped with a special spring that acts to open the door independently of the release device.
Push hinges are equipped with a special spring that acts to open the door independently of the release device.
- Hinge for glass doors and mirrors.
- No drilling of the glass is required.
- Possible fixing inset distance on the door (K): from 0 to 22 mm.
- 110° opening.
- To limit the opening of the hinge, see “Accessories”
- Compatible with all traditional Series 200 mounting plates and with all Domi snap-on monting plates.
- Certified by LGA in conformity with the 15570/08.08 level 3 requirement.
CBGQAC9
DPMSNB
Release device. ø 10 mm, 40 mm length.Beige
DPMSNG
Release device. ø 10 mm, 40 mm length.Grey
DPASNB
Release device to be used to increase the magnetic holding strength. It must always be used together with the DPM. The suggested position of the DPM is the point of pressure on the door. The DPA can be positioned at any point along the opening edge of the door.ø 10 mm, 40 mm length.
Beige
DPASNG
Release device to be used to increase the magnetic holding strength. It must always be used together with the DPM. The suggested position of the DPM is the point of pressure on the door. The DPA can be positioned at any point along the opening edge of the door.ø 10 mm, 40 mm length.
Grey
DP28SN9
Retaining catch to be inserted.ø 11.5 mm
DP38XX91
Retaining catch with adhesive.20x14 mm.
DP39XXG
Adjustable magnetic retaining.ø16.6 mm
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.For Series 100, 200, 700, F, M, N, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.For Series 100, 200, 700, F, M, N, 400 and universal hinges
Stop device SBA237X6
For universal hinges, it limits opening at 90°.
Cover SBAX78A6SN
For universal hinges
Technical pamphlet
Feel the design according to your favourite product
Learn about the other products
Learn about the other products
UNIVERSAL HINGES PUSH
Universal hinges - 110° opening - Standard application
Hinges equipped with a special spring for the opening of handle-less doors
- For doors made with special materials
- Integrated Push system
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES PUSH
Universal hinges - 110° opening - Standard application / half-inset doors / doors with moulded profiles
Hinges equipped with a special spring for the opening of handle-less doors
- Wooden doors
- Integrated Push system
- For doors of small weight and thickness (12-20 mm)
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application
Hinge with integrated soft-close
- Glass doors
- No drilling of the glass is required
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application
Hinge with integrated soft-close
- For doors made with special materials
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application / half-inset doors / doors with moulded profiles
Hinge with integrated soft-close
- Wooden doors
- For doors of small weight and thickness (12-20 mm)
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application
Sprung hinge
- Glass doors
- No drilling of the glass is required
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application
Sprung hinge
- For doors made with special materials
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
UNIVERSAL HINGES
Universal hinges - 110° opening - Standard application / half-inset doors / doors with moulded profiles
Sprung hinge
- Wooden doors
- For doors of small weight and thickness (12-20 mm)
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Series 200 - 110° opening - Standard application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For doors of medium weight and thickness (16-26 mm)
- Wooden doors
- 110° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Series 200 - 94° opening - Standard application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For thicker doors (19-35 mm)
- Wooden doors
- 94° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional one
PUSH
Series 200 - 94° opening - Positive angled application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For thicker doors (19-35 mm)
- Wooden doors
- 94° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional one
PUSH
Series 200 - 94° opening - Crampon hinge
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For thicker doors (19-35 mm)
- Wooden doors
- 94° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Metal profiles (20 mm) - Standard application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For 20 mm-thick doors
- Aluminium-frame doors
- 105° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Metal profiles (20 mm) - Positive angled application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For 20 mm-thick doors
- Aluminium-frame doors
- 105° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Metal profiles (20 mm) - Crampon hinge
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For 20 mm-thick doors
- Aluminium-frame doors
- 105° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
PUSH
Series 200 - 155° opening - Standard application
Hinges equipped with a special spring for the opening of handle-less doors
- Integrated Push system
- For thicker doors (max. 28 mm)
- Wooden doors
- 155° opening
- Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
