SELF-CLOSING

Series 400 Mini hinges - 94° opening - Standard application

Self-close hinge

  • For doors of small weight and thickness (16-26 mm)
  • Wooden doors
  • 94° opening
  • Snap-on fixing with Domi mounting plates, screw fixing with traditional ones
Compact, elegant, very strong mini hinge.
  • 11.5 mm deep metal cup.
  • 26 mm cup diameter.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 8 mm.
  • Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
C4_7A99
Arm 0
C4_7D99
Arm 5
C4_7G99
Arm 9
C4_7P99
Arm 17
Screw cover cap S2BX83H_

Symmetrical steel screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, M, 400 and universal hinges

S2BX83H9 = Nickel
S2BX83H6 = Titanium

Screw cover cap S2MX83H_

Symmetrical steel screw cover cap with embossed logo.
For Series 100, 200, 700, F, M, 400 and universal hinges

S2MX83H9 = Nickel
S2MX83H6 = Titanium

Screw cover cap S2XX83A1
Symmetrical plastic screw cover cap, it can be personalised on request.
For Series 100, 200, 700, F, B, M and 400 hinges
Spacer S6A786XG
Spacer for hinges with 26 mm diameter.
To be used to reduce the cup drilling depth by 1.5 mm
