For profile and thicker doors (max. 40 mm).
- 13 mm deep steel cup.
- 40 mm cup diameter.
- 94° opening.
- Possible drilling distance on the door (K): from 3 to 15 mm.
- Compatible with all traditional Series 200 mounting plates and with all Domi snap-on mounting plates.
CF_7A99
Arm 0
CF_7G99
Arm 11
CF_7P99
Arm 22
Screw cover cap S2BX83H9
Symmetrical steel screw cover cap, it can be personalised on request.For Series 100, 200, 700, F, M, 400 and universal hinges
Screw cover cap S2MX83H9
Symmetrical steel screw cover cap with embossed logo.For Series 100, 200, 700, F, M, 400 and universal hinges
Screw cover cap S2XX83A1
Symmetrical plastic screw cover cap, it can be personalised on request.For Series 100, 200, 700, F, M, 400 and universal hinges
Spacer SFA586XG
Spacer for hinges with 40 mm diameter.To be used to reduce the cup drilling depth by 1.5 mm
Technical information
Documentation
Video
- Automatic closing
- Traditional assembly with Series 200 mounting plates
- Assembly with Domi snap-on mounting plates
- Traditional height adjustment
- Height adjustment by cam
- Depth adjustment with Domi snap-on mounting plates - Model BAV
- Depth adjustment with Domi snap-on mounting plates - Models BAPXR BARXR
- Traditional depth adjustment
- Sideways adjustment
- Fixing: wood screw
- Fixing: knock-in dowel
Technical pamphlet
