SILENTIA+ Series 300 - 94° opening - Hinges with a small operating profile-1

SILENTIA+

Series 300 - 94° opening - Hinges with a small operating profile

Hinges with adjustable integrated soft-close mechanism operated by twin silicone-oil dampers housed in the hinge cup

  • For thicker doors (19-35 mm)
  • Wooden doors
  • 94° opening
  • Screw fixing with traditional Series 300 mounting plates
The state of the soft-close art

Silentia+ allows a perfect and constant closing of the door in any condition, use and application.

The innovative soft-close technology guarantees excellent performances to the complete range of hinges.
Silentia+ includes numerous technological elements in the required spaces and maintains the aesthetics of the hinges of the first generation.

SILENTIA+ Series 300 - 94° opening - Hinges with a small operating profile-2
Silentia+ is also equipped with the innovative switch to delay the decelerating action. The activation of this switch allows, even to special doors, to obtain the ideal decelerating strength.
  • Hinges with adjustable integrated soft-close mechanism operated by twin silicone-oil dampers housed in the hinge cup.
  • The decelerating effect is adjusted by using a simple switch.
  • Hinges for min. 18 mm thick doors.
  • Dimensions of the Ø 35 mm cup.
  • 15.5 mm deep cup.
  • 94° opening.
  • Possible drilling distance on the door (K): from 3 to 9 mm.
  • Compatible with all traditional Series 300 mounting plates.
C3_BAE9
Arm 0
Flange cover cap S2XX85H9
Steel flange cover cap, it can be personalised on request.
For all Series 100, 200, 300, 700, 800 and 900
Flange cover cap S2CX85H9
Steel flange cover cap with embossed logo.
For all Series 100, 200, 300, 700, 800 and 900
Spacer S2XX86
Spacer to reduce the drilling depth for 94°, 105° and 110° hinges.
S2XX86BT = 0.6 mm
S2XX86AT = 1.2 mm
S2XX86KT = 1.8 mm
Gauge D_A_AC_SN
Gauge to check the diameter and the depth of the drilling.
D1A6AC3SN = 12 mm
D2ABACGSN = 15.5 mm
D7A6ACYSN = 13.5 mm
Stop device S2A637XF
It limits opening at about 86°
