MONO
T-Able / T-Able XL
Pull-out drawer table with single telescopic folding leg
- Finishing: Inox Bronzino
- Load Capacity: 100 kg evenly distributed
- Sliding: Aluminium/Aluminium
A balance between form and support.
The Mono collection represents the ideal synthesis of visual lightness and structural solidity. The single support ensures stability and comfort, whilst maintaining a modern, sleek aesthetic.
Solutions designed to blend harmoniously with tabletops and surfaces, offering practicality and fluid movement, built to last.
The Mono collection represents the ideal synthesis of visual lightness and structural solidity. The single support ensures stability and comfort, whilst maintaining a modern, sleek aesthetic.
Solutions designed to blend harmoniously with tabletops and surfaces, offering practicality and fluid movement, built to last.
T-Able / T-Able XL
T-Able is an innovative, space-saving system for extracting a large table from a standard drawer.
In the medium 850 mm version, 2 small tops are used, while in the XL version, 1310 mm, 3 small tops are used.
In addition, its folding telescopic leg guarantees high load capacity (over 100 kg) and stability, meeting the highest safety standards.
The entire system is made of aluminium with Atim’s exclusive guides and technology, which give the whole mechanism greater robustness and great ease of handling.
A large table, fully integrated into the cabinet.
The pull-out system guarantees high stability and load capacity.
The aluminium structure ensures resistance and lightness.
Opening is smooth, designed for frequent use.
Perfect for quickly transforming the available space.
A complete solution, designed to coexist with the environment.
Technical features
- Finishing: Inox Bronzino
- Load Capacity: 100 kg evenly distributed
- Sliding: Aluminium/Aluminium
- Kit caps:
- T-Able: 2.9247231.XX
- T-Able XL: 2.9247251.ΧΧ - Top:
- White chipboard
- T-Able 600: 3.9129876.12 M
- T-Able 900: 3.9129866.12 M - Hinges:
- T-Able 600: 2.9250961.XX
- T-Able 900/1200: 2.9250971.XX
- T-Able XL 600: 2.9250981.XX
- T-Able XL 900/1200: 2.9250991.XX - Design: Arch. Giulio Manzoni, ATIM R&D
- Packaging:
- T-Able 118×18×8 cm 7,5 kg 0,017 m²
- T-Able XL 118×18×8 cm 8 kg 0,017 m² - NOTE: The item does not include the supply of wooden parts.
411/78.1900.22
M - Width: 600 mm
P - Depth: min 540 mm
H - Height: min 120 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 850 mm
Z - Top width: min 555 mm
S - Top thickness: min 16 mm
T - Mechanism height: 745/840
Silent: 78.1900.22
411/78.1910.22
M - Width: 900 mm
P - Depth: min 540 mm
H - Height: min 120 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 850 mm
Z - Top width: min 855 mm
S - Top thickness: min 16 mm
T - Mechanism height: 745/840
Silent: 78.1910.22
411/78.1920.22
M - Width: 1200 mm
P - Depth: min 540 mm
H - Height: min 120 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 850 mm
Z - Top width: min 1155 mm
S - Top thickness: min 16 mm
T - Mechanism height: 745/840
Silent: 78.1920.22
411/78.1900.22X
M - Width: 600 mm
P - Depth: min 520 mm
H - Height: min 150 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 1310 mm
Z - Top width: min 555 mm
S - Top thickness: min 16 mm
T - Mechanism height: 700/795
Silent: 78.1900.22X
411/78.1910.22X
M - Width: 900 mm
P - Depth: min 520 mm
H - Height: min 150 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 1310 mm
Z - Top width: min 855 mm
S - Top thickness: min 16 mm
T - Mechanism height: 700/795
Silent: 78.1910.22X
411/78.1920.22X
M - Width: 1200 mm
P - Depth: min 520 mm
H - Height: min 150 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 1310 mm
Z - Top width: min 1155 mm
S - Top thickness: min 16 mm
T - Mechanism height: 700/795
Silent: 78.1920.22X
