POCKET DOOR SYSTEM Exedra2 Star-1

POCKET DOOR SYSTEM

Exedra2 Star

The evolution of the Exedra system, which enables the simultaneous movement of two linked doors. Exedra2 Star is the version where the compartment that houses the mechanism is always hidden by the cover panel fixed to the front of the system

  • Maximum weight for single door: 25 Kg
  • Doors thickness: min 18 mm - max 25 mm
  • Width of single door: min 450 mm - max 750 mm
  • Doors height: min 1800 mm - max 2600 mm
Unique patented door opening system

The whole mechanism is self-supporting and fixed to the side of the cabinet; there are no load-bearing frontal profiles on either the top or bottom of the cabinet, thus eliminating any need for additional central supports. Thanks to the motion-control system, the handle can be fixed at the edges of the doors, allowing effortless opening and closing with one hand. Furthermore, with the aid of the electric Push kit, it is possible to use both versions on handle-less furniture.

POCKET DOOR SYSTEM Exedra2 Star-2

The system can be used in a host of applications to enable a significant functional optimisation of space, from walk-in wardrobes to larder units for kitchens, home office solutions and in storage applications.

The system does not necessarily have to be placed on the floor, therefore it is possible to create systems raised from the ground or placed on a cupboard or a chest of drawers.

  • DOUBLE pocket door system with cam-assisted door extraction and cushioned door insertion.
  • Door characteristics:
  • Adjustment:
       - vertical adjustment ± 5 mm
       - horizontal adjustment ± 3.5 mm
       - front adjustment: - upper ± 3 mm
                                  - lower ± 2 mm
  • Maximum weight for single door: 25 Kg
  • Doors thickness: min 18 mm - max 25 mm
  • Width of single door – Exedra2 Star: min 450 mm - max 750 mm
  • Doors height: min 1800 mm - max 2600 mm
  • The right mechanism and the left mechanism are independent of each other, therefore it is possible to order them individually.
    If they are installed on the same cabinet, they must be configured as a pair.
VE56KIT0001
Magnets kit to protect doors
VE56KIT0002
Smove kit for internal door
VE56EPP0010
Electric Push kit. Right cabinet side
VE56EPP0020
Electric Push kit. Left cabinet side
VE56KIT0003
Doors alignment kit
VE56KIT0200_7
VE56KIT0200A7 = Frame cover. It can be coated by the customer
VE56KIT0200S7 = Frame cover. Metal grey
