EVOLIFT

Flap door, soft close

Compactness and high levels of performance

  • Wooden doors
  • Aluminium-frame doors
  • Coil-spring movement
  • With covers
  • Door height from 300 to 600 mm
  • Door weight from 1,5 to 18 kg
Smoothness and silent movement

Two strength types dependent on door dimensions and weight. Coil-spring movement with a wide range of adjustment. For use on wooden and alu-framed doors.

Flap door, soft close-2
Neatly-designed covers in white or titanium colour. EvoLift is suitable for a vast range of furniture applications: kitchens and livingroom furniture.
  • Two strength types dependent on door dimensions and weight
  • Coil-spring movement with a wide range of adjustment
  • For use on wooden and alu-framed doors
  • Soft close
  • Neatly-designed covers in white or titanium colour
FRMFXXX_SN9_

FRMFXXXDSN9D: Weak system strength, right cabinet side
FRMFXXXDSN9S: Strong system strength, left cabinet side

FRMFXXXFSN9D: Weak system strength, right cabinet side
FRMFXXXFSN9S: Strong system strength, left cabinet side

Cover SR_M78A_SNXXF

SRDM78AQSNXXF: Right cabinet side, white colour
SRDM78ALSNXXF: Right cabinet side, titanium colour

SRSM78AQSNXXF: Left cabinet side, white colour
SRSM78ALSNXXF: Left cabinet side, titanium colour

C2_6A99

Hinge for wooden doors or for alu-framed doors 45 mm

Full overlay / A crank - 0 mm

C2P6A99 = Wood screw, Nickel finish
C2R6A99 = Dowel, Nickel finish


C2Z6A99

Hinge for alu-framed doors min. 17 mm max. 24 mm

Full overlay / A crank - 0 mm

BAPGM39/16
Mounting plate for hinges
DLZXBH9
Support for plate for alu-framed doors min. 17 mm max. 24 mm
