LAPIS Series 700 - 110° opening - With covers-1

LAPIS

Series 700 - 110° opening - With covers

Hinges with adjustable integrated soft-close mechanism operated by twin silicone-oil dampers housed in the hinge cup

  • For doors of medium weight and thickness (16-26 mm)
  • Wooden doors
  • 110° opening
  • Snap-on fixing only with In-Line Domi mounting plates
The revolution in form and style

Lapis is characterized by two covers moving with the hinge elements simultaneously whilst hiding the technical components. This product stands out due to its refined aesthetics, its unique and revolutionary shape and its up-to-date and innovative design.

No fewer than 12 finishes and 144 combinations offer a high personalization level, meeting the requirements of producers of any kind of furniture.

LAPIS Series 700 - 110° opening - With covers-2

Lapis is also equipped with the innovative switch to delay the decelerating action. The activation of this switch allows, even to special doors, to obtain the ideal decelerating strength.


  • Hinges with adjustable integrated soft-close mechanism operated by twin silicone-oil dampers housed in the hinge cup.
  • The decelerating effect is adjusted by using a simple switch.
  • Hinges for min. 16 mm thick doors.
  • 13.5 mm deep cup.
  • 110° opening.
  • Possible drilling distance on the door (K): from 3 to 6 mm.
  • Adaptable only with In-Line Domi snap-on mounting plates (BAP).
C716AE9
Arm 0
C716GE9
Arm 9
P7A0A09

SATIN CHROME
Lapis cabinet side
Arm 0

P7A9A09

SATIN CHROME
Lapis cabinet side
Arm 9

P7SXA09SN

SATIN CHROME
Lapis door side

P7A0A10

SATIN METAL BLACK
Lapis cabinet side
Arm 0

P7A9A10

SATIN METAL BLACK
Lapis cabinet side
Arm 9

P7SXA10SN

SATIN METAL BLACK
Lapis door side

P7A0A1W

SATIN GOLD
Lapis cabinet side
Arm 0

P7A9A1W

SATIN GOLD
Lapis cabinet side
Arm 9

P7SXA1WSN

SATIN GOLD
Lapis door side

P7A0A0C

CHAMPAGNE
Lapis cabinet side
Arm 0

P7A9A0C

CHAMPAGNE
Lapis cabinet side
Arm 9

P7SXA0CSN

CHAMPAGNE
Lapis door side

P7A0A06

GLOSSY CHROME
Lapis cabinet side
Arm 0

P7A9A06

GLOSSY CHROME
Lapis cabinet side
Arm 9

P7SXA06SN

GLOSSY CHROME
Lapis door side

P7A0A0N

GLOSSY METAL BLACK
Lapis cabinet side
Arm 0

P7A9A0N

GLOSSY METAL BLACK
Lapis cabinet side
Arm 9

P7SXA0NSN

GLOSSY METAL BLACK
Lapis door side

P7A0A0I

STAINLESS STEEL
Lapis cabinet side
Arm 0

P7A9A0I

STAINLESS STEEL
Lapis cabinet side
Arm 9

P7SXA0ISN

STAINLESS STEEL
Lapis door side

P7A0A05

GRAPHITE
Lapis cabinet side
Arm 0

P7A9A05

GRAPHITE
Lapis cabinet side
Arm 9

P7SXA05SN

GRAPHITE
Lapis door side

P7A0A08

GLOSSY GOLD
Lapis cabinet side
Arm 0

P7A9A08

GLOSSY GOLD
Lapis cabinet side
Arm 9

P7SXA08SN

GLOSSY GOLD
Lapis door side

P7A0A07

OLD BRASS
Lapis cabinet side
Arm 0

P7A9A07

OLD BRASS
Lapis cabinet side
Arm 0

P7SXA07SN

OLD BRASS
Lapis door side

P7A0AA3

BLACK
Lapis cabinet side
Arm 0

P7A9AA3

BLACK
Lapis cabinet side
Arm 9

P7SXAA3SN

BLACK
Lapis door side

P7A0A11

MATT WHITE
Lapis cabinet side
Arm 0

P7A9A11

MATT WHITE
Lapis cabinet side
Arm 9

P7SXA11SN

MATT WHITE
Lapis door side
