VERTICAL SLIDING SYSTEM

Mover

Vertical sliding system for wall cabinet doors. The action of the system is synchronised and controlled, enabling the door to be held in any position

Max. door weight from 6 (13 lbs) to 21 kg (46 lbs)
Width from 900 (35-7/16") to 2400 mm (94-1/2")
Height from 480 (18-7/8") 600 mm (23-5/8")
The door can be held in any position

Innovative and highly functional system

Mover does not require double side panels or counterweights and so maximises the available space in the cabinet

Need more info about the product?

Mover allows the vertical adjustment of the door. Particularly suitable in restricted spaces as an alternative to conventionally-opening doors, notably in bathrooms and galley kitchens. It is also popular in living room applications for display and media cabinets.

Find out more

Door dimensions:
- 900 W x 480 H mm (35-7/16" x 18-7/8")
- 1200 W x 480 H mm (47-7/32”x 18-7/8")
- 1800 W x 480 H mm (71-1/16”x 18-7/8")
- 2400 W x 480 H mm (94-1/2”x 18-7/8")

- 900 W x 600 H mm (35-7/16”x 23-5/8”)
- 1200 W x 600 H mm (47-7/32”x 23-5/8”)
- 1800 W x 600 H mm (71-1/16”x 23-5/8”)
- 2400 W x 600 H mm (94-1/2”x 23-5/8”)
Telescopic guides thickness 20 mm;
Height adjustment ± 3 mm (± 1/8”);
Door weight adjustment ± 1 kg (±2 lbs);
