LIVING

Evolution +39

Pull-out cabinet table with bridge leg

Finishing Runners: Inox Bronzino
Finishing Leg: Grey RAL 7012
Load Capacity: 100 kg evenly distributed
Sliding: Aluminium / Aluminium

The Living collection strikes a perfect balance between innovation, craftsmanship and attention to contemporary living needs.

Designed to blend seamlessly into living spaces, the Living version stands out for its reduced depth: a smart solution that allows you to optimise your space without compromising on comfort or style. Ideal for modern, multifunctional settings, it allows you to enjoy your space with greater freedom and harmony.

Every element is carefully crafted to ensure reliability, precision and durability, showcasing Italian know-how that combines tradition with a vision for the future.

Evolution +39

In its +39 version, Evolution can be installed in cabinets with a minimum depth of 390 mm.

The mechanisms, designed to allow use of the entire cabinet door, are supplied complete with a painted steel bridge leg with adjustable floor wheels and are also available in the Naked version without front door.

Need more info about the product?

Technical features

Finishing:
- Runners: Inox Bronzino
- Leg: Grey RAL 7012
- Naked Version(N): Leg: RAL 9005 Matt black
Load Capacity: 100 kg evenly distributed
Sliding: Aluminium / Aluminium
Kit caps: 2.9247241.XX
Hinges:
- Evolution +39 600: 2.9250961.XX
- Evolution +39 900: 2.9250971.XX
- Evolution Naked+39 600: 2.9250961.XX
- Evolution Naked +39 900: 2.9250971.XX
Design: Arch. Giulio Manzoni, ATIM R&D
Packaging (2):
- Evolution +39 411/39.1610.25 118×18×8 cm 4,5 kg 0,017 m3 + 57×77×8 cm 8 kg 0,035 m3
- 411/39.1611.25 118×18×8 cm 4,5 kg 0,017 m3 + 87×88×8 cm 11 kg 0,055 m3
- Evolution +39 Naked 411/39.1610.25N 118×18×8 cm 4,5 kg 0,017 m3 + 57×77×8 cm 8 kg 0,035 m3
- 411/39.1611.25N 118×18×8 cm 4,5 kg 0,017 m3 + 87×88×8 cm 11 kg 0,055 m3
NOTE: The item does not include the supply of wooden parts. The Naked Version (N) does not include crosspieces for fixing the door.

Versions

39.1610.25

M - Width: 600 mm
P - Depth: min 390 mm
H - Height: min 120 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 690 mm
Z - Top width: min 555 mm
S - Top thickness: min 16 mm
T - Mechanism height: 730/755 mm

39.1611.25

M - Width: 900 mm
P - Depth: min 390 mm
H - Height: min 120 mm
S1 - Side thickness: 15/20 mm
E - Top opening: 690 mm
Z - Top width: min 855 mm
S - Top thickness: min 16 mm
T - Mechanism height: 730/755 mm
