F70 PUSH - CANADA

Full-extension

Heavy-duty fully synchronized drawer runner

78 kg Static load capacity
70 kg Dynamic load capacity
Meets and exceeds ANSI A156.9-2020 Grade 1
Available in the full range of lengths from 350 mm to 750 mm

A new generation of heavy duty drawer slides

Featuring an ingenious fully integrated synchronized system by way of a rack and pinion mechanism. Suitable for every drawer in the house and any commercial application also thanks to the optional synchronizer kit (sold separately).

Push: Salice patented fully integrated Push to open system for handle-less cabinets and more. A slight pressure of the drawer front is enough to open the drawer.

Need more info about the product?

The synchronization system for Push to Open F70 runners has been developed to ensure that wider drawers can be opened with minimum effort. The system links the two runners, which then become a single element; applying pressure on any part of the drawer front (even at the extremities), is sufficient for the Push devices to release and consequently for the drawer to open.
The synchronization can be used with any drawer width; its functionality is at its best with drawers wider than 80 cm.

Find out more

78 kg Static load capacity
70 kg Dynamic load capacity
Full extension with a synchronized mechanism
Available in the full range of lengths from 350 mm to 750 mm
Integrated Push opening system
Elongated holes for depth and height adjustment
Adjustable clips allow for easy drawer insertion and removal
The drawer is latched when closed
Tool free height adjustments + 2.5 mm
Tool free depth adjustments +/- 3 mm
Tool free side adjustments +/- 1.5 mm
Optional:
- tool free tilt adjustment +3 mm
- F70 Push Synchronizer
12 mm (1/2”) to 16 mm (5/8”) drawer thickness
Compatible with Lineabox drawers
Finish: bright zinc-plated
100% Made in Italy

Versions

Components

Accessories

G7E6P350XXB

Runner length: 350 mm

Min. depth of the cabinet: 360 mm

G7E6P400XXB

Runner length: 400 mm

Min. depth of the cabinet: 410 mm

G7E6P450XXB

Runner length: 450 mm

Min. depth of the cabinet: 460 mm

G7E6P500XXB

Runner length: 500 mm

Min. depth of the cabinet: 510 mm

G7E6P550XXB

Runner length: 550 mm

Min. depth of the cabinet: 560 mm

G7E6P600XXB

Runner length: 600 mm

Min. depth of the cabinet: 610 mm

G7E6P650XXB

Runner length: 650 mm

Min. depth of the cabinet: 660 mm

G7E6P700XXB

Runner length: 700 mm

Min. depth of the cabinet: 710 mm

G7E6P750XXB

Runner length: 750 mm

Min. depth of the cabinet: 760 mm

AFCGXX3B

F70 Locking devices - side and depth adjustments
- Dual metal/plastic construction
- For all F70 runner versions
- Tool free lateral and depth adjustments
- Pre-drilling recommended ø 2.5 mm (3/32”)
- Mounts to the bottom or to the drawer front

APKF7X51150

F70 Push synchronizer

The synchronisation system for Push-open F70 runners has been developed to ensure that drawers of any width can be opened with minimum effort.
The system links the two runners, which thus become a single element; a pressure at any point of the drawer frontal (even at the extremities), is sufficient for the Push mechanism to release and consequently for the drawer to self-open.

SGD704UGXA

Drilling templates for drawers

Pre-drilling for the clips reduces the possibility of splitting the wood, thus assuring the correct and level installation of the clips. The correct and level mounting assures a smooth assembly and operation of the drawer slide.
