PACTA With Push system for single doors-1

PACTA

With Push system for single doors

System for fall flaps

  • Wooden doors
  • Door height from 280 to 400 mm
  • Door weight from 1,5 to 9,5 kg
  • 90° opening
  • Decelerated opening action
Pacta confers a decelerated opening action and the fall of the door is gradual and controlled.

In the fully-open position, the door and base panel are aligned, creating a uniform and flat surface.
Pacta comes in a variety of finishes. Its applications are numerous: in living room and kitchen cabinets, to create desks in children’s furniture or for writing surfaces and table extensions in hotel furniture.
We suggest that you use the central hinge for cabinets over 900 mm width.

PACTA With Push system for single doors-2

Pacta is a compact hinge for fall flaps which operates without the need for additional stays or cables.

  • Hinges with Soft Opening and Push to open feature.
  • Standard drilling of the door ø 35.
  • 13 mm deep cup.
  • 90° opening.
  • Fixed K = 4.5 mm.
  • Minimum door height of 11“; Maximum door height of 16”.
  • Minimum door thickness of 16 mm; Maximum door thickness of 28 mm.
  • Overlay 17 mm ± adjustment.
  • Attachment to the cabinet with in-line, snap-on mounting plate (BAPGR29/16).
  • Side-, front and vertical door adjustment.
  • Central hinge for cabinets over 900 mm width to be used.
  • Covers available in numerous finishes.
FRBKFEP_SN9
Push opening
SRXB78A1XXXX_

Cover
WHITE

SRXB78AQXXXX_

Cover
GLOSSY WHITE

SRXB78AIXXXX_

Cover
STAINLESS STEEL

SRXB78AMXXXX_

Cover
GRAY

SRXB78ACXXXX_

Cover
CHAMPAGNE

SRXB78A0XXXX_

Cover
SATIN METAL BLACK

SRXB78ANXXXX_

Cover
GLOSSY METAL BLACK

DPMSNB
Release device. ø 10 mm, 40 mm length.
Beige
DPASNB
Release device to be used to increase the magnetic holding strength. It must always be used together with the DPM. The suggested position of the DPM is the point of pressure on the door. The DPA can be positioned at any point along the opening edge of the door.
ø 10 mm, 40 mm length.
Beige
DP28SN9
Retaining catch to be inserted with pin.
ø 11.5 mm
DP38XX91
Retaining catch with adhesive.
20x14 mm surface.
For use with aluminum doors or smooth surfaces.
DP39XXG
Adjustable magnetic catch. Inserted into the door.
ø16.6 mm
D007SN_
Smove D007SNG or D007SNB can be added to the cabinet for a soft close feature.
For best function, install the Smove 2 - 3 inches from the bottom.
FRCK59RUXXX1
Central hinge with cover cap
Suggested for cabinets over 900 mm width
WHITE
FRCK59RUXXXQ
Central hinge with cover cap
Suggested for cabinets over 900 mm width
GLOSSY WHITE
FRCK59RUXXXI
Central hinge with cover cap
Suggested for cabinets over 900 mm width
STAINLESS STEEL
FRCK59RUXXXM
Central hinge with cover cap
Suggested for cabinets over 900 mm width
GRAY
FRCK59RUXXXC
Central hinge with cover cap
Suggested for cabinets over 900 mm width
CHAMPAGNE
FRCK59RUXXX0
Central hinge with cover cap
Suggested for cabinets over 900 mm width
SATIN METAL BLACK
FRCK59RUXXXN
Central hinge with cover cap
Suggested for cabinets over 900 mm width
GLOSSY METAL BLACK
Pozi driver D2A7XCXCP

The #2 Pozi driver is for use on all adjustment screws and all Pozi drive attachment screws
